Features
- Front inlet gun, internal body in brass and steel.
- The seat and the ball are in stainless steel.
- Ergonomic construction, with minimum fatigue for trigger opening
Specifications
- Inlet: 3/8″ NPT F
- Outlet: 1/4″ NPT F
- Working Pressure: 2,900 psi
- Maximum Pressure: 3,200 psi
- Nominal Flow: 30 L/min
- Temperature: 160°C
Range Review
| Part # | Inlet | Outlet | Weight |
|---|---|---|---|
| 145 30.0100.20 | 1/4″ Bsp F | 1/4″ Bsp F | 262 gr |
| 145 30.0100.30 | 1/4″ Bsp M | 1/4″ Bsp F | 256 gr |
| 145 30.0100.00 | 3/8″ Bsp F | 1/4″ Bsp F | 272 gr |
| 145 30.0100.60 | 3/8″ Bsp M | 1/4″ Bsp F | 265 gr |
| 145 30.0100.40 | A M22 | 1/4″ Bsp F | 280 gr |
| 145 30.0100.50 | 3/8″ Npt F | 1/4″ Npt F | 276 gr |
