Features

• Triplex plunger pump, available in 6 versions.
• Patent pending, symmetrical power end design featuring top and bottom mounting holes allowing for easy left-to-right shaft conversion.
• Pressure packing design with integrated  cooling system
• Orthogonally fitted valves.
• Splash lubrication.

Specification

• 250 Bar @ 1450 Rpm
• 200 Bar @ 1750 Rpm
• 51 Lpm @ 1450 Rpm
• 62 Lpm @ 1750 Rpm
• 33 Hp, 24.3 kW @ 1450 Rpm
• 32 Hp, 23.6 kW @ 1750 Rpm
• 30 mm male shaft
• Nickel-plated cast iron manifold
• 40 °C max water temperature
• 1″1/4BSP female inlet
• 1″BSP female outlet
• Call the sales office for installation advice
