CHEMICAL TRANSFER PUMP – YANMAR DIESEL

BE 2″ Yanmar Diesel Powered Chemical Transfer Pump

BE “Yanmar Powered” chemical transfer pumps are specifically designed with a fiberglass-reinforced poly pump and impeller for pumping non-solid chemicals.  These high-flow pumps, fitted with Nitrile o-rings and gaskets, are commonly used for applications such as agricultural chemical transfer, diesel fuel, brine or salt water, and marine salvage.

Performance

• 550 L/min. Flow Rate (max)
• 7 M Suction Lift (max)
• 30 M Total Head (max)

Pump

• Chemical Resistant Pump
• 2″ BSP Suction Port
• 3″ BSP Discharge Port
• Fiberglass Reinforced Pump Body & Impeller
• Standard with Nitrile seals & gaskets
• Carbon / Ceramic / Nitrile Mechanical Seal
• Optional Viton Seals Available

Unit & Frame

• Black Powder Coated Roll Frame

Engine

• Yanmar Diesel Engine
• Air-Cooled. 4 Stroke Diesel Engine
• Electric Start
• 3.5 L Fuel Tank
• Low Oil Alert
