Features
- Commercial Honda engine with excellent weight to power ratio. Designed to be used all day, everyday.
- Direct drive system connects the engine to the pump for a compact and efficient power transfer.
- Commercial grade General triplex pump featuring die-cast body, forged brass manifold, one-piece plungers, thermal release valve and improved heat dissipation.
- External unloader provides superior cooling and versatility to further enhance pump life.
- Heating coil is ignited by a 12v Wayne burner that is fueled with diesel. Includes AGM deep cycle battery.
- The burner can be turned off and controlled with the adjustable thermostat that can be set up to 89°/193°F.
- Commercial grade accessories included are a 50 foot high-pressure hose, spray gun wand assembly, and five spray nozzles.
- Powder coated steel frame with four 12” flat free tires for stability and to handle rough terrain. Roll cage design protects the components while allowing easy access to use or maintain.
- A lift point is built into the frame to allow the use of a crane to lift it onto a truck or trailer.
- Frame includes mounting brackets for quick installation onto trucks or trailers by removing the wheels.
Specifications
- Pump Style: Triplex
- Unloader: External
- Series: Commercial
- Engine: Honda GX200
- Pump – Brand: General
- Pump – Model: TP2530J34
- Pressure: 2700 Psi
- Flow: 10.6 L/min (2.8 gpm)
- CC: 200
- Weight: 480 lbs
