Flow Switch ST-7 3/8F

ST-7 Flow Switches

The ST-T is a newly developed version of the flow switch having a completely new operating principle. In this new development, a robust and industrial micro switch is inserted instead of the usually supersensitive REED-contacts with low switching capacity. The micro switch makes it possible to realize a significantly higher electrical output though having a longer working life.

The electrical and water-hydraulic components of the flow switch are completely separated. The construction of the flow switch allows mounting the electrical parts independent of the hydraulic components within the series production process.

When fitting together chassis and switch box both parts of the flow switch are connected again. Due to the mature engineering low switching points are realized in spite of maximum water quantities. The pressure drop within the flow switch is only 1.5 bar at 30 L/min.

Features

• Switch-on points: 1.5 L/min
• 1.5 L closed
• 0.8 L open
