General Pump 3/8″ Expansion Valve

Warning: An outlet of water must be directed away from people or animals.

Features

• Replaces a burst disc and can be used repeatedly
• To be used on or after the coil to prevent the coil from over-heating to the point of steam explosion
• The valve will stay open until the water/pump is turned off, then will reset
• Designed and manufactured in the USA

Specifications

• Flow Rating: 7.6 L/min to 22.7 L/min
• Pressure Rating: 6000 PSI Max
• 3/8″ MNPT Outlet
• 154°C Max Temperature
• 303 Stainless Steel Body, 316 Stainless Steel Ball
