Features
- The PowerEase R300 is a 301 cc (18.4 cu-in) single-cylinder air-cooled 4-stroke internal combustion general-purpose gasoline engine with a horizontal shaft.
- The PowerEase R300 engine has an OHV design; flat suction valve carburettor; recoil starter or electric starter, transistorized magneto ignition (TCI) system and centrifugal mechanical governor system.
- The R300 motor has an 80.0 mm (3.15 in) cylinder bore and a 60.0 mm (2.36 in) piston stroke with a compression ratio of 8.5:1.
- It produced 12.0f horsepower at 3,600 rpm and 18 N·m (1.83 kg·m, 13.27 ft·lb) of torque at 2,500 rpm.
- Electric Start
- 1″ Keyed Shaft
Specifications
- Model: R300
- Type: 4-stroke, OHV, single cylinder
- Displacement: 301 cm 3 (18.4 cu-in)
- Shaft: 1″ Keyed
- Max. horsepower: 12.0 HP at 3,600 rpm
- Cont. horsepower: 10.0 HP @ 3600 RPM
- Max. torque (crank PTO): 18 N·m (1.83 kg·m, 13.27 ft·lb) at 2,500 rpm
- Carburettor: Flat suction valve carburetor
- Cooling system: Forced-air
- Ignition system: Transistorized magneto ignition (TCI)
- Lubricating system: Splash
- Starting system: Recoil / electric starter
- Stoping system: Ignition primary circuit ground
- Fuel used: Unleaded gasoline (octane number 86 or higher)
- PTO shaft rotation: Counterclockwise (from PTO shaft side)
