B70
Direct oil heaters are highly efficient devices that provide large volumes of instant heat where it is required. They are ideal for open or well-ventilated areas like factories, warehouses or construction sites. Master direct heaters are known for their efficiency, robustness, ease of use and operational safety.
Key features
- High air flow
- Two oil filters – oil tank filter and suction filter
- Thermally protected motor
- Electronic flame control with photocell
- Stainless steel combustion chamber
- Oil tank with level indicator
- Designed for easy handling and transportation
- Easy maintenance
Product specifications
Specifications | Units | B 70 |
---|---|---|
Heating power | kW | 20 |
Heating power | Btu/h | 68,300 |
Heating power | kcal/h | 17,200 |
Air flow | m³/h | 400 |
Fuel autonomy | h | 10 |
Thermostat control | Analogue or digital | |
Fuel consumption | l/h | 1.9 |
Power supply | V/Hz | 220/240/50-60 |
Electric power | kW | 0.18 |
Rated current | A | 0.8 |
Protection | IP41 | |
Tank capacity | l | 19 |
Product size (l x w x h) | mm | 745 x 300 x 405 |
Box size (l x w x h) | mm | 810 x 350 x 450 |
Net/gross weight | kg | 15/18 |
Pallet | pcs | 15 |
Dual voltage | No |
